Part # 12333
$254.71
New Dual Outlet Oil/Fuel Filters with secondary outlet port. The new fuel/oil filters eliminate the need for additional fittings and y-blocks allowing you to feed separate systems from one filter. Features 10-Micron filter element. P/N 12333 features ORB-10 inlet and outlet ports with ORB-06 secondary port. Port plug for secondary port included.
Fits: Filter w/ Dual Outlet, 10-m Fabric Element, In-Line, ORB10 Inlet / Outlet plus ORB-06 Outlet, Bright-Dip Black, 2" OD.
Installation note: dual outlet filter; 10-micron fabric element; ORB-10 inlet and outlet ports; secondary ORB-06 port; black anodized finish
In the box: Filter Element, Gasket Or Seal
| Color | Black |
| End 1 Gender | Female |
| End 2 Gender | Female |
| Filter Element Material | Cellulose |
| Filter Housing Color | Black |
| Filter Housing Diameter | 2.0 IN |
| Filter Housing Finish | Anodized |
| Filter Housing Length | 5.5 IN |
| Filter Housing Material | Billet Aluminum |
| Fitting Type | AN-10 |
| Flow Rate | 2000 lbs/hr |
| Fuel Filter Style | Inline |
| Fuel Type | Gas / Diesel |
| Housing Material | Aluminum |
| Inlet Attachment | Female Thread |
| Inlet Outside Diameter | AN-10 |
| Inlet Quantity | 1 |
| Inlet Size | AN-10 |
| Length | 5.5 IN |
| Maximum Fuel Pressure (psi) | 70 PSI |
| Micron Rating | 10 |
| Mounting Type | External |
| Outlet Attachment | Female Thread |
| Outlet Outside Diameter | AN-10 |
| Outlet Quantity | 1 |
| Outlet Size | AN-10 |
| Outside Diameter | 2.0 IN |
| Outside Diameter (In) | 2.0 IN |
| Overall Length | 5.5 IN |
| Overall Length (In) | 5.5 IN |
| Quantity | Sold individually. |
| Shape | Straight |
| Smallest Particle Filtered | 10 microns |
| Universal Or Specific Fit | Universal |
