Part # 11110
$1,120.59
Certified to ISO 8846, SAE J1171; United States Coast Guard Requirements for Ignition Protection; Fire Resistance. Carbureted Engines: up to 2300 HP naturally aspirated and up to 1700 HP forced air induction. Fuel Injected Engines: up to 1900 HP naturally aspirated and up to 1400 HP forced air induction.
Features & Benefits
Certified to ISO 8846, SAE J1171 & United States Coast Guard Requirements for Ignition Protection & Fire Resistance.
Fits: Marine 1200 HP EFI Pump.
Installation note: Marine 1200 HP EFI Pump; Certified to ISO 8846, SAE J1171 and United States Coast Guard Requirements for Ignition Protection and Fire Resistance.
In the box: Mounting Bracket
| EFI HP on E85 | 2300 |
| EFI HP on Gas | 1900 |
| Fuel Delivery Type | Carburation & Fuel Injection |
| Fuel Type | Gas/E85 |
| Inlet Outside Diameter | ORB - 12 |
| Inlet Type | Female Thread |
| Integrated Controller | No |
| Internal Or External | External Or Internal |
| Marine Approved | No |
| Maximum Current Draw | 12 @ 40 psi |
| Maximum Flow Rating | 1250 |
| Maximum Pressure | 90 |
| Motor Style | Brushed |
| Negative Ground | Yes |
| Outlet Outside Diameter | ORB - 10 |
| Outlet Type | Female Thread |
| Pulse Width Modulation Compatible | Yes |
| Pump Design | Rotary Vane |
| Series | Eliminator |
| Terminal Gender | Male |
| Terminal Quantity | 2 |
| Terminal Type | Threaded Stud |
| Universal Or Specific Fit | Universal |
| Voltage | 12 |
| Wire Quantity | 0 |
