Part # 550-510-3AE
$1,518.95
Want to make the switch from the original Sniper EFI to Sniper 2 and don't want to rewire your system? The new Sniper 2 upgrade kits are designed to do exactly that! Included with each Sniper 2 Plug and Play upgrade system is an adapter solution that connects your existing Sniper EFI wiring harness to a Sniper 2 throttle body in minutes. Simply remove your Sniper EFI throttle body from the intake manifold, unplug all connectors, reinstall the Sniper 2 throttle body, and plug the Sniper EFI 2 adapter harness into your existing main harness. Cycle your ignition key, run a fresh wizard on the display of your choice, and enjoy the benefits of Sniper 2 EFI.
Features & Benefits
Sniper 2 is compatible with the complete Sniper EFI Ecosystem that includes plug-n-play Hyperspark Ignition systems (coil, ignition box and distributor), fuel systems (fuel lines, fuel pump hangers), multiple displays and more
Fits: Sniper 1 to Sniper 2 Upgrade kit with External Fuel Pressure Regulator, Fittings, Hose
In the box: Fuel Hose, Fuel Injectors, Fuel Pressure Regulator, Throttle Position Sensor
| Accelerometer Support | No |
| Boost Control | No |
| CAN-BUS Support | Yes |
| CFM | 800 |
| Coast Guard Approved | No |
| Coil Per Cylinder Ignition Support | No |
| Datalogging Support | Yes |
| Dry Nitrous Control | No |
| EGT Support | No |
| Finish | Shiny |
| Flange Style | 4150 |
| Forced Induction HP@60PSI | 575 |
| Forced Induction Support | Yes |
| Fuel Pressure | 58.5 PSI |
| Fuel Pressure Regulator | Yes |
| Fuel System | Master Kit |
| Height | 3.28" |
| Ignition Timing Control | Yes |
| Individual Cylinder Fuel Corrections | No |
| Injector Quantity | 4 |
| Injector Size | 100 lb/hr @ 58.5 PSI |
| Inlet / Outlet Size | 9/16-18 Female O-Ring (AN 6) |
| Knock Retard Support | No |
| MAP Sensor | 2 Bar |
| Max Horsepower Rating | 650 Naturally Aspirated |
| Maximum Injector Quantity Supported | 4 |
| Model | 4150 EFI Conversion Throttle Body |
| Multi-Stage Nitrous Control | No |
| Naturally Aspirated HP@60PSI | 650 |
| PDM | No |
| Power Distribution Module | No |
| Progressive Nitrous Control | No |
| Self-Tuning | Yes |
| Traction Control Support | No |
| Transmission | All |
| User Interface | 3.5 in Handheld |
| User-Tuneable | Yes |
| Wet Nitrous Control | No |
| e85 Support | No |
