Part # 556-112
$112.95
This coil is designed for use with Holley HP and Dominator ECU's, as well other EFI systems that can drive "smart" ignition coils. Although it is designed for high powered race applications, it can be used on street driven vehicles as well.
Features & Benefits
Mating Connector - Delphi P/N 12162825 “Pull to Seat”
Fits: For Dominator, HP ECU's, and other EFI systems
Installation note: The wire must be fed through the back of the housing, out the front, and then the pin crimped. Pull the wire back in to seat it. Always use proper crimping tools to ensure a proper connection.
| Coil Type | Holley SmartCoil |
| Color | Black |
| Connector Gender | Female |
| Height | 1.86" |
| Ignition Wire Terminal Type | HEI Style Tower |
| Mounting Bolt Pattern | 74mm |
| Mounting Hole Quantity | 2 |
| Oil Filled | No |
| Overall Length | 4.3" |
| Terminal Gender | Male |
| Width | 3.6" |
